Product details

More Information
  • 3 x XLR inputs and 6 x XLR outputs
  • Complete digital sound processing solution
  • 8-band parametric EQ with low/high shelf
  • Limiter / Crossover / Filter
  • Independent processing for each output channel
  • 24-bit 96kHz AD/DA convertors
  • 40-bit internal processing
  • USB / RS232 and RS485 connectivity
  • User friendly software included
  • Password protection for venue install
Technical Specifications


Model Name – SC-36

Input Effects – Gain, Mute, Link, High-pass Filter, Low-pass Filter, Noise Gate, 8-Band Parametric EQ, 31-Band Graphic EQ, Phase, Delay

Output Effects – Crossover, 5-Band Parametric EQ, Gain, Mute, Compressor / Limiter, Phase, Delay, Link

Software – Included via CD or download; full matrix input/output control with intuitive UI

User Presets – 20

Total Units Linkable – Up to 255 via RS485 and optional wireless router

Audio Inputs – 3 × Balanced XLR

Audio Outputs – 6 × Balanced XLR

USB – 1 (PC Control)

Ethernet – 1

RS232 Port – 1

Frequency Response – 20 Hz – 20 kHz

Signal-to-Noise Ratio – >155 dBu

Distortion (THD) – <0.005% @ 1 kHz (0 dBu)

Max Output Level – +20 dBu

Impedance – <500 Ω

D/A Converters – 24-bit Sigma-Delta

Sampling Rate – 96 kHz

Display – 20 × 2 LCD parameter/function display, 5-segment LED level display

Dimensions – 480 × 50 × 45 mm

Weight – 2.62 kg
