The Versadrive speaker management system offers all the digital signal processing and detailed control that a live sound engineer needs.


Whether we like it or not, it’s a reality that PA systems are complex.  A lot of time is spent selecting the best loudspeaker and amplifier combinations, and systems can easily grow.  Its therefore essential to maintain control to ensure the best quality sound throughout the rig.

Packaged into a neat 1U rack design, an intuitive and concise front panel with LCD screen enables engineers to make essential adjustments to the speaker configuration with accuracy.
Enquire Now

Product details

More Information
  • 3 x XLR inputs and 6 x XLR outputs
  • Complete digital sound processing solution
  • 8-band parametric EQ with low/high shelf
  • Limiter / Crossover / Filter
  • Independent processing for each output channel
  • 24-bit 96kHz AD/DA convertors
  • 40-bit internal processing
  • USB / RS232 and RS485 connectivity
  • User friendly software included
  • Password protection for venue install
Technical Specifications


Model Name – SC-36

Input Effects – Gain, Mute, Link, High-pass Filter, Low-pass Filter, Noise Gate, 8 PEQ, 31-band Graphic EQ, Phase, Delay

Output Effects – Crossover, 5 PEQ, Gain, Mute, Compressor / Limiter, Phase, Delay, Link

Software – Included via CD or download; full matrix input/output control with intuitive UI

User Presets – 20

Total Units Linkable – Up to 255 via RS485 and optional wireless router

Audio Inputs – 3 × Balanced XLR

Audio Outputs – 6 × Balanced XLR

USB – 1 (PC Control)

Ethernet – 1

RS232 Port – 1

Frequency Response – 20 Hz – 20 kHz

Signal-to-Noise Ratio – >155 dBu

Distortion (THD) – <0.005 @ 1 kHz (0 dBu)

Max Output Level – +20 dBu

Impedance – <500 Ω

D/A Converters – 24-bit Sigma Delta

Sampling Rate – 96 kHz

Display – 20 × 2 LCD Parameter / Function Display, 5-Segment LED Level Display

Dimensions – 480 × 50 × 45 mm

Weight – 2.62 kg
