Product details

More Information
  • 700W RMS / 1400W Program /2800W Peak
  • 135dB Max SPL
  • 15″ Woofer
  • 3.2″ HF Titanium Compression Driver
  • Flexible point-source passive array series
  • 100° x 10° long-throw waveguide
  • Bi-amped modes
  • Dual angle pole mount sockets
  • M10 x 11 & Fly Track Rigging points
  • Speakon inputs
  • Fly individually / in pairs / in array formations
  • Suitable for many different venues and formations
Technical Specifications


Configuration – 2-Way

Frequency Response – 45 Hz – 20 kHz

Power (RMS / Program / Peak) – 700 W / 1400 W / 2800 W

Impedance – 8 Ω

Max SPL – 135 dB

Low Frequency Transducer – 15 in

High Frequency Transducer – 3.2 in Titanium Compression Driver

Nominal Coverage – 100° × 10°

Waveguide Type – Square

Rigging Points – M10 × 11 & 4 Fly Track

Rigging Point Max Rated Weight – 500 kg

Bi-Amp Mode Switch – Yes

Inputs – 2 × Speakon

Net Weight – 34.1 kg / 75 lb

Gross Weight – 36.5 kg / 80.3 lb

Dimensions (H × W × D) – 625 × 390 / 199.3 × 370.7 mm
