This Crossover Is Ready for Any Rig

The Behringer Super-X Pro CX3400 is a fully versatile crossover that's perfect for any professional live sound rig. The CX3400 is capable of either 2-way or 3-way stereo, or 4-way mono operation. Equipped with 24dB/octave Linkwitz-Riley filters, the CX3400 gives you the steep crossover bands you demand. Each output features an independent level control and phase inversion switch. For use with a subwoofer, the CX3400 also includes a low-frequency output summing option. For the flexibility you need in configuring your PA system, check out the Behringer Super-X Pro CX3400.

Enquire Now

Product details

Technical Specifications
  • High-Precision Active Crossover

  • Stereo 2-Way / Stereo 3-Way / Mono 4-Way Operation

Audio Performance


  • 24 dB/octave Linkwitz-Riley crossover filters

  • Flat summed frequency response with zero phase difference

  • Low-noise audio circuitry

  • Wide frequency response: 5 Hz – 100 kHz

  • Dynamic Range: > 114 dB

  • Signal-to-Noise Ratio: > 93 dB (unweighted)

Inputs & Outputs


  • 2 × Balanced XLR Inputs

  • Balanced XLR Outputs (configuration depends on operating mode)

  • Servo-balanced, gold-plated XLR connectors

  • Mono "Low Sum" Output for subwoofer applications

Processing Features


  • Individual Output Limiters

  • Adjustable Time Delay for driver alignment

  • Constant Directivity (CD) Horn EQ

  • Individual Output Gain Controls

  • Individual Output Mute Switches

  • Individual Phase Reverse Switches

  • Switchable 25 Hz Low-Cut Filter on each input

Indicators


  • Signal LEDs

  • Limiter LEDs

  • Mute Status LEDs

  • Power LED

Power Supply


  • Internal universal switch-mode power supply

  • 100–240 V AC, 50/60 Hz

Dimensions


  • 44 × 483 × 147 mm (H × W × D)

    (1U Rack Mount)

Weight


  • Approximately 2.3 kg (5.1 lb)

Key Features


  • Stereo 2-way, Stereo 3-way and Mono 4-way operation

  • Professional loudspeaker management

  • Precise frequency separation

  • Built-in speaker protection limiters

  • Adjustable delay for phase alignment

  • CD horn compensation

  • Ideal for professional PA systems, installations and live sound applications.
